Biotube® Low-Head Pump Vaults (LHV)

Orenco’s Biotube Low-Head Pump Vaults use patented Biotube filtration to screen effluent for low-head effluent pumps. They can be used in two-compartment septic tanks and dose tanks. The passively self-cleaning design minimizes filter buildup. The pump vault float switch assembly and filter cartridge can be removed for maintenance independent of the vault itself.

  • Biotube filtration in passively self-cleaning configuration
  • 17.88in (455mm) vault diameter
  • 61.25in (1556mm) vault height
  • Supports up to 15in diameter pumps
  • 1/8in (3.2mm) screen mesh
  • 12.5ft2 filter surface area
  • 3.8ft2 filter flow area
  • Durable one-piece polyethylene construction
  • Removable float switch assembly (sold separately)
  • Ball valve for easy removal from tank
